USV 01-LR Autonomous
A long-range autonomous surface vessel engineered for defense, ISR, maritime surveillance, and tactical unmanned operations.
USV 01-LR Autonomous
A long-range autonomous surface vessel engineered for defense, ISR, maritime surveillance, and tactical unmanned operations.
Baseline build specifications
Every Novielli is custom-built. Use these figures as a baseline — final configuration is tuned to mission requirements.
- Vessel Type
- Long-Range Autonomous Surface Vessel / Tactical USV
- Length Overall
- 31.0 ft / 9.45 m
- Beam
- 9.8 ft / 2.99 m
- Draft
- 1.5 ft / 0.46 m
- Dry Weight
- 5,800 lb / 2,631 kg
- Estimated Loaded Weight
- 8,500–10,500 lb
- Hull Material
- 5083 marine-grade aluminum
- Hull Type
- Low-profile deep-V aluminum autonomous surface vessel hull
- Engine Configuration
- Single, twin, waterjet, or custom autonomous propulsion configuration
- Recommended Horsepower
- Twin 150 HP
- Maximum Horsepower
- 500+ HP
- Fuel Capacity
- 250 gal / 946 L
- Estimated Top Speed
- 36–44 mph
- Cruise Speed
- 22–30 mph
- Estimated Range
- 400–550 nautical miles
- Passenger Capacity
- Unmanned operation / 2 service personnel when required
- Payload Capacity
- 2,000 lb
- Fresh Water Capacity
- Not required / mission-configurable
- Holding Tank Capacity
- Not required / mission-configurable
- Build Type
- Custom-built to mission requirements
- Hull Warranty
- 25-year structural hull warranty
Built for long-range autonomous operations
The USV 01-LR Autonomous is a defense-grade long-range unmanned surface vessel built for tactical maritime operations, ISR missions, persistent surveillance, force protection, and autonomous patrol. Its low-profile aluminum hull, long-range fuel capacity, and mission-configurable payload architecture support extended unmanned deployments across coastal, littoral, and open-water environments.
Mission systems & equipment
- Remote and autonomous control architecture
- Integrated sensor mast
- Baseline ISR electronics package
- Radar and AIS integration
- EO/IR camera package capability
- GPS/INS navigation
- SATCOM and long-range communications capability
- Encrypted command-and-control systems
- Redundant control and power architecture
- Mission-configurable payload bay
- Operator console / ground control station integration
- Custom defense, surveillance, or research equipment integration
Tactical graphics
Low-visibility tactical finish with minimal markings for defense and government deployments. Suggested markings:
- "USV 01-LR"
- Hull identification number
- Small NOVIELLI BOATS branding
- Optional agency seal or unit identifier
- Optional low-contrast tactical stripe package
Starting MSRP
Each USV 01-LR Autonomous is quoted as a custom unmanned maritime platform. Starting MSRP reflects a premium long-range autonomous configuration with welded 5083 aluminum construction, low-profile deep-V hull, remote/autonomous operation capability, integrated sensor mast, baseline maritime surveillance electronics, long-range fuel capacity, and mission-ready systems architecture. Final pricing varies by autonomy package, sensor suite, communications architecture, propulsion package, payload integration, control station requirements, testing, training, support, and customer-specific operational requirements.
- Starting MSRP
- From $3,950,000
- Estimated Custom Build Range
- $3,950,000–$9,850,000+
- Turnkey Agency Program Estimate
- $5,950,000–$12,500,000+
- Pricing Basis
- Defense-grade long-range autonomous surface vessel with 5083 aluminum construction, low-profile tactical hull design, remote/autonomous control architecture, integrated sensor mast, baseline ISR electronics, and mission-ready payload infrastructure
- Customization Factors
- Autonomy level, propulsion configuration, radar, EO/IR camera package, AIS, GPS/INS navigation, SATCOM or long-range communications, encrypted command-and-control systems, sensor mast configuration, payload integration, redundant control systems, onboard power architecture, operator console package, software integration, sea trials, training, support, spares, branding, and customer-specific mission requirements
Spec Note —All specifications are baseline estimates and may vary based on propulsion package, fuel load, autonomous systems, sensor package, communications equipment, mission payload, electronics, and customer build requirements. Higher-output custom configurations may be available subject to engineering review.
